- 25%
Ortofon Alpha
795 SEK595 SEK
Lägsta pris de senaste 30 dagarna795 SEKKlassisk Ortofon MM pickup i 500-serien som designades för musikälskaren snarare än 'audiofilen'.
"The Ortofon Series 500 was created for music lovers, not just hi-fi enthusiasts. It is designed for individuals who appreciate the intimacy, immediacy, and 'liveness' of real music."
Modellen 'alpha' tillverkades i bulk exklusivt för Pro-Ject Audio men är i övrigt identisk med en Ortofon 510 mk2 MM pickup. Pickupen levereras i vadderat kuvert utan tillbehör till mycket förmånligt pris!
- Betala säkert med Swedbank Pay
- Har du frågor? Kontakta oss
Beskrivning
Art.nr: ORALPHA
- Type: MM
- Fixing: Half-inch mount
- Output voltage at 1000 Hz, 5 cm/sec: 3 mV
- Channel Balance at 1 kHz: 1.5 dB
- Channel separation at 1 kHz: 23 dB
- Channel separation at 15 kHz: 15 dB
- Frequency range at -3 dB: 20-23,000 Hz
- Frequency response: 20-20.000 Hz + 2 /- 2 dB
- FIM distortion at recommeded tracking force, DIN 45,542: < 1%
- Tracking ability at 315 Hz at recommended tracking force: 70 µm
- Compliance, dynamic, lateral: 25 µm/mN
- Stylus type: Elliptical
- Stylus tip radius: r/R 8/18 µm
- Equivalent stylus tip mass: 0.3 mg
- Tracking force range: 1.25-1.75 g (12.5-17.5 mN)
- Tracking force, recommended: 1.5 g (15 mN)
- Tracking angle: 20°
- Internal impedance DC resistance: 1 kOhm
- Internal inductance: 580 mH
- Recommended load resistance: 47 kOhm
- Recommedned load capacitance: 200-400 pF
- Cartridge colour (Body/Stylus): Black/Black
- Cartridge weight: 5 g
